Winch Motor Reversing Solenoid Contactor Relay 6-Terminal Trombetta Style Large 214-1211A11 214-1231-A61-06

Replaces these part numbers:For EMS 31-8970 318970For Arrowhead LRW6001For Cole Hersey 24450 24450BX 24450-BX CH24450For Rexco 7-1205 71205For Trombetta 214-1211A11 214-1231A11 214-1211A11-06 214-1211A51 214-1211A61 2141211A11 2141231A11 2141211A1106 2141211A51Compatible With:Winch Motors, Snow Plow & Spreader Motors, Windlasses, Hydraulic Pump Motors & Other Reversible Motors that Normally Require Multiple Solenoids 75 Amp Make and Break:Maximum on time: 5 Minutes.125 Amp Make and Break:Maximum on time: 30 Seconds.150 Amp Make and Break:Maximum on time: 0.5 Seconds.**Allow 5 minute cool down time after pushing solenoid to maximum limit!** Specifications:Description: SolenoidVoltage: 12Surge Amps: 150Condition: NewMounting: Flat 180 (F180)Duty Cycle: IntermittentCase Material: PlasticNumber of Terminals: 6

• Replaces these part numbers:<br>For EMS 31-8970 318970<br>For Arrowhead LRW6001<br>For Cole Hersey 24450 24450BX 24450-BX CH24450<br>For Rexco 7-1205 71205<br>For Trombetta 214-1211A11 214-1231A11 214-1211A11-06 214-1211A51 214-1211A61 2141211A11 2141231A11 2141211A1106 2141211A51<br><br><br>
• New 12 Volt 6 Terminal Solenoid Reversing Relay This solenoid will work only with Permanent Magnet Motors. It will not work with the older style motors with copper field coils. This solenoid switch is used to reverse polarity on Permanent Magnet winch motors with 2 terminal posts. It will not work on Winch motors with 3 terminal posts
• Enhance performance, direct replacement, easy installation, high reliability.
• Professional Installation is Highly Recommended (No Instruction Included)
